What we stand for

Quality

 Quality is always the result of high intention, sincere effort, intelligent procedure and skillful performance.

To abide our highest Quality demands we forceful try to improve our quality management. Therefore we account for the engineer standards EN ISO 9001:2008, ISO/TS 16949 and environment policy.

Consistent Quality management  made us to a leading manufacturer of pressure-, pull- and legsprings.

Reliability

 Reliability is the result of a fair relationship and responsible contact with each other.

We deliver your springs at a constant high quality and your requested time.

A continuous production supervision and scheduling ensure the timely production of your product. Rely on us!

Precision

 Precision results from the interplay of innovative thinking, straight-line action and accurate approach.

With our advanced machinery  we can produce accurate parts with low production tolerances.

Send us the drawing of your component and learn more about our manufacturing capabilities.

About us

logo-about


Mission statement

Our company founded in 1969 mainly focuses on the design and manufacture of customized springs in wire diameters ranging from 0.1 to 12 mm. With our experience in development and design of precision springs we offer custom products, which are perfectly adapted to the needs of our customers. With our advanced machinery we manufacture your product in almost any batch sizes. The high quality is due to our continual improving quality assurance  standards guaranteed.

Chronik

1969 – Company founded by Mr. Hans Ziller – 2 man company in Boehmenkirch – workshop about 50 sqm.

1973 – Relocation of production in poststrasse 45 in Boehmenkirch – 5 employees

1984 – Move into the new built corporate buildings in Ahornstrasse in Boehmenkirch – about 1400 square meters of production area – 25 employees.

1990 – Rebranding to Hans Ziller GmbH.

1994 – Production area expansion about 2800 sqm – set the course for a furthermore positive company groth – 50 employees.

2008 – Stock – and production area expansion about 2200 square meters – Enlargement of the administration wing. Beginning with the education of industrial mechanics for spring technology.

2010 – Total production area ​​about 6100 square meters and about 90 employees.

2012 – Expansion of the machinery – powerful personnel growth: about 120 employees – education and student support are amplified in the industrial and business area.

2013 – Certification to ISO / TS 16949, DIN EN ISO 50001:2011 und DIN EN ISO 14001:2009

2015 – Expansion of the product portfolio to 12,00 mm wire diameter – enhanced alignment to medium-sized companies – upgrade of the skills in assembling, automation and handling

In numbers

45

 years of expirience

125

employees

6100

 square meters production

Products

Learn more about our products



Standard springs

Our standard program includes springs according to DIN – standard. These springs gain more and more importance in construction.

Special springs

The implementation of individual customer requirements into functional components is our top priority. Our specialty are springs from CrSi alloy wires, shot-peened and heat set for highest dynamic and thermal load.





Standard springs

Hergestellt nach DIN Norm

 Springs according to DIN

Our standard program includes springs according to DIN – standard. These springs gain more and more importance in construction. Our standard springs are manufactured of spring wire according to EN 10270-1-DH/SH and Stainless steel according to EN 10270-3-1.4310.

When you are interested in our Standard springs, you can download the Standard spring program in our download area. The .zip file includes all components of the range Pressure Springs, Tension Springs and hole-/shaft rings and the pricelist.

Advising on technical matters or for an individual offer, you can contact our Technical Sales.

federpyramide

Pressure Springs
Our Standard Pressure springs are produced in a wide range with wire thickness spanning 0.10 to 10,00 mm. Our standard springs are manufactured of spring wire and Stainless steel.

In our current price list are they net price listed, considering their price groups of all springs. They prices are ex work plus VAT. All price groups are in stair portions declared. When you raise your Purchase quantity gets the spring corresponding cheaper. Ask for a no obligation quote. Consider the minimum order values are 25 €.

Stock list

Zugfedern
Our Standard Tension springs are produced in a wide range with wire thickness spanning 0.20 to 5,00 mm. Our standard springs are manufactured of spring wire and Stainless steel. At both ends there is a closed German loop according to DIN 2097 Picture 3. The loop position is 0 alternatively 180 degree. The loops are closed. However it is possible to have an opening cut into the loop at additional cost.

In our current price list are they net price listed, considering their price groups of all springs. They prices are ex work plus VAT. All price groups are in stair portions declared. When you raise your Purchase quantity gets the spring corresponding cheaper. Ask for a no obligation quote. Consider the minimum order values are 25 €.

Stock list
Standardbohrungs-/ Wellenringe
Our Standard Hole-/ Shaft rings are produced in a wide range with wire thickness spanning 0.80 to 3,20 mm. Our standard springs are manufactured of spring wire and Stainless steel.

In our current price list are they net price listed, considering their price groups of all springs. They prices are ex work plus VAT. All price groups are in stair portions declared. When you raise your Purchase quantity gets the spring corresponding cheaper. Ask for a no obligation quote. Consider the minimum order values are 25 €.

Stock list

Special springs

According to your request

The implementation of individual customer requirements into functional components is our top priority. Our specialty are springs from CrSi alloy wires, shot-peened and heat set for highest dynamic and thermal load. We manufacture in a wide range with wire thickness spanning 0.10 to 10,00 mm.

For Surface treatment (e.g. Dacromat, Deltamagni, galvanic treatment, etc.) we are operate with competent business partner together.
Reliability and flexibility are a standard for us, which we face today responsibly and in the future.

Advising on technical matters or for an individual offer, you can contact our Technical Sales.

federpyramide
Pressure Springs
The modern machinery enabled us to produce in a wide range with wire thickness spanning 0.10 to 10,00 mm. Strict constructions, custom-made design or unusual materials are not a problem for us because of perfect skilled and flexible employees. Our specialty is heat set springs for highest dynamic and thermal load.

Area of operation:

  • Fuel Injection
  • Brake systems
  • Security systems

Materials:

  • Spring wire according to EN 10270-1-DH/SH
  • Oil tempered spring steel
  • Stainless steel according to EN 10270-3-1.4310

Surface treatment:

  • Shoot peened
  • Rotofinishing
  • Colouring
  • Colour coding
  • Phosphating
  • Varnishing
  • Galvanic coats
  • Powder coat
  • Dacromat coat
  • Delt-Tone
  • Polyseal
Tension Springs

We are manufacture customer-designed Tension Springs. At both ends there is a closed German loop according to DIN 2097 Picture 3 with wire thickness spanning 0.25 to 6,50 mm, hook loops and other loop forms with wire thickness spanning 0.40 to 3,00 mm.

Area of operation:

  • Damping system
  • Clutch system

Materials:

  • Spring wire according to EN 10270-1-DH/SH
  • Oil tempered spring steel
  • Stainless steel according to EN 10270-3-1.4310
  • Different special materials

Surface treatment:

  • Shoot peened
  • Other Surface treatment on request
Hole-/ Shaft rings

The modern machinery with 23 variable axes enabled us to produce wire bent parts in different forms and remarks, in a wide range with wire thickness spanning 1,00 to 3,00 mm.

Area of operation:

  • Clutch system
  • Engines

Materials:

  • Spring wire according to EN 10270-1-DH/SH
  • Oil tempered spring steel
  • Stainless steel according to EN 10270-3-1.4310
  • Different special materials

Surface treatment:

  • Shoot peened
  • Rotofinishing
  • Colouring
  • Colour coding
  • Phosphating
  • Varnishing
  • Galvanic coats
  • Powder coat
  • Dacromat coat
  • Delt-Tone
  • Polyseal

Environment protection

zertifikate

Produce economical

Our company always been anxious to avoid unnecessary emissions and redundant waste. All employees are trained on our objectives in terms of environmental policy, hence an environmentally friendly manufacture of our products is guaranteed.

We include all existing environmental regulations in our business planning and try to avoid environmentally harmful substances best possible. Our products are mostly designed that even a easy disposal is possible.

In the field of packaging technology, we try to switch to reusable packaging.



Contact

Get in touch with us via the contact form or call us. We look forward to your inquiry!
